TH0600 Precision AC Current Transformer

TH0600 Precision AC Current Transformer is based on broadband current transformer technology. It can convert nominal current from 0.1 A to 10 kA AC into a voltage or current output in a certain proportion and maintains a high proportion uncertainty.
Availability:
Quantity:
  • TH0600

  • TUNKIA

TH0600 Precision AC Current TransformerTH0600 Precision AC Current Transformer

1. Summary

TH0600 precision AC current transformer is based on broadband current transformer technology. It can convert nominal current from 0.1 A to 10 kA AC into a voltage or current output in a certain proportion and maintains a high proportion uncertainty.


2. Features

Supports two current access modes, through core and direct connected type respectively.

Direct connected type with the input current of 0.1 A... 200 A。

Through-core type with the input current of 500 A... 10 kA。

The secondary output signal is optional for voltage (I/V) or current (I/I).

Type I/I: Optimal ratio uncertainty of 5 ppm

Type I/V: Optimal ratio uncertainty up to 10 ppm

Measurement frequency: 40 Hz~2.5 kHz.

Optional digital display function and support digital signal output.


3. Applications

Establishment of an AC current precision measurement system

Calibrate an AC current source or ammeter

Calibrate AC current transformers/sensors

Calibrate the intercurrent I/V conversion standard


3.1 Application of TH0600 (Type I/V)

☆ Set up precision current test system

TH0600 Set up precision current test system

It can be used with AC test power supply or constant current source to form a precision current test system.

Provide accurate and stable AC current signals for test devices and loads.



☆ Calibrate AC high current source / meter

TH0600 Calibrate AC high current source / meter

It can be used to calibrate AC high current standard sources/meters with precision voltmeters.


☆ Build a high-current power/energy measurement system

TH0600 Build a high-current power/energy measurement system

TH0600 ( I/V Type) can be used with V/V conversion equipment such as TH0150 broadband voltage divider, TH0180 precision AC and DC high voltage divider, etc.), TH2000 vector voltage analyzer to form a high-current power/energy precision measurement system.

It is used to measure the output power of high-power power supply, the efficiency of conversion equipment, calibrate high-current power source, power meter and other equipment.


3.2 Application of TH0600 (Type I/I)

☆ Calibrate instrument transformer and I/V converter

TH0600 Calibrate instrument transformer and I/V converter

If the selected TH0600 is proportional to the instrument transformer under test, it can be calibrated using the difference method.

TH0600 Calibrate instrument transformer and I/V converter

If the TH0600 selected is not proportional to the transformer or I/V converter under test, it can be calibrated using the comparative method

Note: The DUT is a current transformer, and an external standard resistor must be connected for I/V conversion.




4. Specifications

4.1 Direct I/I conversion standard

Model

Primary

Nominal current

(A)

Secondary

Nominal current

(A)

Load resistance

(Oh)

Measurement accuracy

(± μA/A, corresponding full-scale value). @50Hz

Phase shift

(μrad, corresponding full-scale value). @50Hz

TH060 0-I-D-01A-01A-5

0.1

0.1

100

5

80

TH060 0-I-D-02A-01A-5

0.2

0.1

50

5

50

TH060 0-I-D-05A-01A-5

0.5

0.1

20

5

15

TH060 0-I-D-1A-01A-5

1

0.1

10

5

10

TH060 0-I-D-2A-01A-5

2

0.1

10

5

10

TH060 0-I-D-5A-01A-5

5

0.1

10

5

10

TH060 0-I-D-10A-01A-5

10

0.1

10

5

10

TH060 0-I-D-20A-01A-5

20

0.1

10

5

10

TH060 0-I-D-50A-01A-5

50

0.1

10

5

10

TH060 0-I-D-100A-01A-5

100

0.1

10

5

10

TH060 0-I-D-200A-1A-5

200

1

10

5

10

Measuring range: ±(10~120%)*FS; Measurement frequency: 40 Hz~2.5 kHz


4.2 Through-core I/I conversion standard

Model

Primary

Nominal current

(A)

Secondary

Nominal current

(A)

Load resistance

(Oh)

Measurement accuracy

(± μA/A, corresponding full-scale value). @50Hz

Phase shift

(μrad, corresponding full-scale value). @50Hz

TH0600-I-T-200A-01A-20

200

0.1

10

20

20

TH0600-I-T-500A-01A-10

500

0.1

10

10

10

TH0600-I-T-1kA-1A-10

1 k

1

1

10

10

TH0600-I-T-2kA-1A-10

2 k

1

1

10

10

Measuring range:±(10~120%)*FS; Measurement frequency: 40 Hz~2.5 kHz


4.3 Direct I/V conversion standard

Model

Primary

Nominal current

(A)

Secondary

Nominal voltage

(V)

Measurement accuracy(

± 1×10-6, corresponding full-scale values). @50Hz

Phase shift

(μrad, corresponding the full-scale value). @50Hz

TH0600-U-D-0.1A-1 V-30

0.1

1

30

30

TH0600-U-D-0.2A-1V-30

0.2

1

30

30

TH0600-U-D-0.5A-1 V-30

0.5

1

30

30

TH0600-U-D-1A-1 V-30

1

1

30

30

TH06 0 0-U-D-2A-1 V-30

2

1

30

30

TH06 0 0-U-D-5A-1 V-30

5

1

30

30

TH06 0 0-U-D-10A-1 V-30

10

1

30

30

TH06 0 0-U-D-20A-1 V-30

20

1

30

30

TH06 0 0-U-D-50A-1 V-30

50

1

30

30

TH06 0 0-U-D-100A-1 V-30

100

1

30

30

TH06 0 0-U-D-200A-1 V-30

200

1

30

30

Measuring range: ± (10~120%)*FS; Measurement frequency: 40 Hz~2.5 kHz


4.4 Through-core I/V conversion standard

Model

Primary

Nominal current

(A)

Secondary

Nominal voltage

(v)

Measurement accuracy

( ± 1×10-6, corresponding full-scale values). @50Hz

Phase shift

(μrad, corresponding the full-scale value). @50Hz

TH0600-U-T-200A-1 V-30

200

1

30

30

TH0600-U-T-500 A-1 V-30

500

1

30

30

TH0600-U-T-1K A-1 V-30

1 k

1

30

30

TH0600-U-T-2K A-1 V-30

2 k

1

30

30

TH06 0 0-U-T-3k A-1 V-30

3 k

1

30

30

TH06 0 0-U-T-5 k A-1 V-30

5 k

1

30

30

TH06 0 0-U-T-6k A-1 V-30

6 k

1

30

30

TH06 0 0-U-T-10k A-1 V-30

10 k

1

30

30

Measuring range: ± (10~120%)*FS; Measurement frequency: 40 Hz~2.5 kHz


5. General Specifications

Power supply

——

Warm-up time

——

Temperature performance

Working temperature: 18°C~28°C; Storage temperature: -10°C ~ 55°C

Humidity performance

Operating humidity: < 80% @ 30°C, < 70% @ 40°C, < 40% @ 50°C

Storage humidity: (20%~80%) R·H, no condensing

altitude

< 3000 m


6. Ordering Information

TH0600 Ordering Information
