TS4510 Type A B Permeameter

TS4510 Permeameter is mainly used as an excitation device for open-circuit magnetic specimen such as bars, rods, and strips to test their DC magnetic properties. Bar specimen cross section: round (Φ10mm), square (10mm×10mm). Sheet specimen: sheet or strip ( width 30 mm). Users can customize corresponding magnetic pole pieces according to the above specimen shapes. Measuring systems that can be equipped with A/B type magnetic permeability meters include: TS4000, TS5300, TS1000, TS1300.

Model:
TS4510
Brand:
TUNKIA


Availability:



Inquire

TS4510 Type A / B Permeameter

TS4510 Type A B Premeameter

1. Summary

Primarily used as a magnetizing device for open-circuit magnetic samples such as bars, rods, and sheets to measure their DC magnetic properties.
Cross-section of rod-shaped samples: Circular (typically φ10 mm), square (typically 10 mm × 10 mm), etc. Sheet-shaped samples: Plates or strips (typically 30 mm wide).
Users can customize corresponding magnetic pole pieces based on the above sample shapes.

2. Specifications

Model	TS4510-A	TS4510-B
Type	Type A Permeameter	Type B Permeameter
Range of H	( 1 ~ 200 ) kA/m	( 1 ～ 50 ) kA/m
Coil	Field Coil	Rogowski-Chattock Coil
Specimen Length L	≥ 250 mm	≥ 100 mm
Dimension (L × W × H)	490 mm × 330 mm × 240 mm	580 mm × 220 mm × 270 mm
Weight	About 65 kg	About 53 kg
Note: The maximum achievable magnetic field depends on the load capacity of the power supply.
