TS7500 / TS7510 Single Sheet Tester

The Single sheet tester is an accessory of magnetic properties measuring system for electrical steel , E.g. TS1100 / TS1200 / TS1300 / TS3000.The Single sheet tester can measure the magnetic properties of Single sheet specimens of various sizes.Single sheet tester with basic edition, upgrade edition and multiple sizes is available.The Single sheet tester of upgrade edition adds yoke loss winding and demagnetization winding.Magnetic field measurement methods: M.C and H-coil.The upgraded monolithic magnetometer adds yoke loss windings and demagnetization windings. The cutting and placement of specimens shall comply with IEC60404-3.

Availability:

Quantity:



Inquire Add to Basket

Model:
TS7500 / TS7510
Brand:
TUNKIA

TS7500 / TS7510 Single Sheet Tester

1. Summary

l The Single sheet tester is an accessory of magnetic properties measuring system for electrical steel , E.g. TS1100 / TS1200 / TS1300 / TS3000.

l The Single sheet tester can measure the magnetic properties of Single sheet specimens of various sizes.

l Single sheet tester with basic edition, upgrade edition and multiple sizes is available.

l The Single sheet tester of upgrade edition adds yoke loss winding and demagnetization winding.

l Magnetic field measurement methods: M.C and H-coil.

l The upgraded monolithic magnetometer adds yoke loss windings and demagnetization windings.

l The cutting and placement of specimens shall comply with IEC60404-3.

2. Specifications

Type	Model	Specimens Size (W × L)	Specimens Thickness	Measurement Method	Maximum Magnetization Field	Working Temperature	Frequency
Basic Edition	TS7500	500 mm × 500 mm	0.1 mm～0.5 mm	M.C	10 kA/m	0℃～45℃	≤100 Hz
Upgrade Edition	TS7510-A	500 mm × 500 mm	0.1 mm～0.5 mm	M.C	10 kA/m	0℃～45℃	≤100 Hz
	TS7510-B	300 mm × 300 mm	0.1 mm～0.5 mm	M.C	10 kA/m	0℃～45℃	≤100 Hz
	TS7510-C	100 mm × 300 mm	0.1 mm～0.5 mm	M.C	10 kA/m	0℃～45℃	≤100 Hz
	TS7510-D	30 mm × 300 mm	0.1 mm～0.5 mm	M.C	10 kA/m	0℃～45℃	≤100 Hz
	TS7510-A-HM	500 mm × 500 mm	0.1 mm～0.5 mm	M.C / H-Coil	10 kA/m	0℃～45℃	≤100 Hz
	TS7510-B-HM	300 mm × 300 mm	0.1 mm～0.5 mm	M.C / H-Coil	10 kA/m	0℃～45℃	≤100 Hz
	TS7510-C-HM	100 mm × 300 mm	0.1 mm～0.5 mm	M.C / H-Coil	10 kA/m	0℃～45℃	≤100 Hz
	TS7510-D-HM	30 mm × 300 mm	0.1 mm～0.5 mm	M.C / H-Coil	10 kA/m	0℃～45℃	≤100 Hz
